Slurry and effluent storage is a productivity lever: keep clean water out, get capacity back

Article summary: Storage shortfalls are often driven by rainwater and clean water sneaking into “dirty” systems, not just herd size or shed time. Irish monitoring shows slurry and soiled water volumes can be underestimated, with water ingress varying a lot farm to farm. A short checklist of fixes (guttering, diversions, roofing, leak repairs) can recover meaningful storage capacity. The aim is simple: keep clean water clean, keep dirty water contained, and create more buffer for better spreading decisions.



When storage gets tight, the default answer is often “we need a bigger pond” or “we need another tank”.

Sometimes that’s true. But a surprising amount of storage pressure is self-inflicted, because clean water is being allowed to become dirty water.

Teagasc data from Ireland is a good reminder: slurry and soiled water volumes are often underestimated, and the amount of extra water getting into storage can vary widely between farms. In other words, two farms with the same cows can end up with very different volumes to store, purely due to how much clean water is getting into the system.

The good news: that means you may have “hidden capacity” sitting there already, without pouring a single cubic metre of concrete.

What “hidden capacity” really means

You do not lose storage capacity only when you add cows. You also lose it when you add water you never meant to store, such as:

  • Rainfall off roofs and clean hardstands that drains into dirty areas

  • Run-off from uncovered high-traffic yards

  • Leaks and overflows (troughs, pipes, wash-down taps, floats)

  • Wash water volumes that creep up over time

Every extra litre does three things:

  1. It consumes storage (your buffer disappears sooner).

  2. It dilutes nutrients (more volume to spread for the same nutrient value).

  3. It increases workload and risk (more agitation, more pumping, more urgent spreading decisions).

A simple way to spot the problem: watch what happens after rain

If the level in your slurry store or effluent pond jumps noticeably after rain, you likely have a separation problem.

A useful rule of thumb for quick thinking:

  • Litres of rain run-off = catchment area (m²) × rainfall (mm)

So even a small uncovered area adds up quickly:

  • 200 m² yard × 10 mm rain = 2,000 L (2 m³) into storage

  • 500 m² yard × 25 mm rain = 12,500 L (12.5 m³) into storage

That is “capacity” you could have kept available for genuine effluent, and it arrives exactly when you least want it.

The yard-walk audit: find where clean water becomes your storage problem

Do this as a 30 to 60-minute walk with two goals:

  • Identify where clean water is entering dirty zones

  • Identify where dirty water is entering storage unnecessarily

Start at the highest point of the yard and follow water flow like you are tracing a fence line.

Look for:

  • Roof water: downpipes discharging onto dirty concrete, into channels, or directly into collection areas

  • Gutters: sagging, blocked, undersized, missing sections, leaking joints

  • Yard grading: clean areas draining across dirty areas (or vice versa)

  • Kerbs and diversion channels: missing or broken kerbing allowing mixing

  • Uncovered high-traffic areas: stand-off pads, feedpads, dairy yards, loafing areas

  • Leaks: trough ballcocks, hydrants, cracked pipes, wash-down taps, automatic drinkers

  • Overflows: sumps, tanks, plate coolers, wash systems, poorly set floats

If you only fix one thing, fix the one that routes the most clean water into dirty areas during rainfall.

Quick wins checklist (low cost, high impact)

These are the fixes that often give the fastest “capacity back”.

1) Gutters and downpipes: make roof water someone else’s problem

  • Clear gutters, check fall, replace broken brackets.

  • Ensure downpipes are large enough and actually catch the runoff (no “missing the pipe” splash).

  • Pipe roof water to a clean outfall, not across yards.

  • Add simple leaf guards or clean-out points where blockages are common.

2) Divert clean yards away from dirty yards

  • Re-grade or add small diversion lips so clean concrete drains to clean drainage.

  • Add kerbing or channel drains to stop clean run-off crossing dirty zones.

  • Reduce the size of the “dirty catchment” by fencing or gating off clean areas.

3) Roof (or partially roof) uncovered dirty collection areas

If you have an uncovered area that is always contaminated (feedpad, stand-off area, holding yard), roofing it can be one of the biggest capacity wins.

Even partial roofing over the highest-traffic section can meaningfully reduce runoff.

4) Fix leaks and overflows (the silent storage killer)

  • Check troughs and floats weekly in wet periods.

  • Look for constantly damp patches or green strips where water runs.

  • Repair drips now, not “after calving” or “after silage”.

  • Set float levels correctly and check overflow routes.

5) Change the cleaning method before you change the storage

  • Scrape first, hose last.

  • Use squeegees and targeted wash-down rather than flooding the whole yard.

  • Keep solids out of channels so you do not need extra water to move them.

Medium wins (often worth it if storage is a recurring pinch point)

If you are repeatedly tight on storage, these tend to pay back quickly in avoided stress and fewer emergency decisions:

  • Separate clean and dirty drainage properly (two systems, not one “everything goes somewhere” approach)

  • Upgrade yard surfaces so they are easier to scrape clean (less water required)

  • Add proper diversion structures (kerbs, cut-off drains, sumps) where topography forces flow

  • Reduce the effective dirty area by redesigning stock access and traffic routes

  • Cover storage where suitable and safe (reduces direct rainfall and can improve overall system control)

Translate the terms (so this works anywhere)

Different regions use different language, but the principle is the same: keep clean water out of the dirty system.

  • Slurry (IE/UK) = liquid manure, often mixed with washings

  • Effluent (AU/NZ) = dairy shed wash-down, manure, feedpad and yard runoff stored in an effluent pond

  • Soiled water (IE/UK) = “dirty water” from yards and washings that is not quite slurry, but still needs control

  • Dirty water (AU/NZ) = contaminated runoff and washings that should not enter clean drains

  • Stand-off area = loafing pad, sacrifice area, holding area (often a major runoff contributor)

  • Feedpad = feed platform, stand-off pad with feeding, high-traffic yard (often worth roofing or diverting)

If you keep the categories clear (clean water, soiled/dirty water, slurry/effluent), the fixes translate cleanly across systems.

What you unlock when you get this right

When you stop storing water you never meant to store, you create:

  • More buffer to wait for better spreading conditions

  • Less urgent, lower-risk decisions in wet periods

  • More concentrated nutrients, so you can get more value per load

  • A more predictable system, which makes planning easier year-round

How Pasture.io fits into this

Storage is only useful if it gives you control over timing and placement.

Once you have your system behaving, Pasture.io helps you turn that control into pasture performance by:

  • Recording effluent or slurry applications by paddock

  • Tracking responses through the season (growth rates, covers, rotation outcomes)

  • Keeping your nutrient and paddock history tidy for reporting and decision-making

Hidden capacity is not just an infrastructure win. It is a management win.
